Plant List

CNC Milling machines

1-off DOOSAN DNM350AX 5 axis

Machining Centre
15kW High Torque
Table Size Ø350mm
BT40 40 Tool Magazine
Through Spindle High Pressure Coolant
Spindle Speed 0-12,000rpm

1-off DAEWOO MYNX 540

Vertical Machining Centre
15kW High Torque
Table Size 1200mm x 500mm
Travel X1020mm x Y510mm x Z625
BT40 30 Tool Magazine
Through Spindle High Pressure Coolant
Spindle Speed 0-8,000rpm

1-off DOOSAN DNM400

Vertical Machining Centre
15kW High Torque
Table Size 920 x 435mm
Travel X762mm x Y430mm x Z510
BT40 30 Tool Magazine
Through Spindle High Pressure Coolant
Spindle Speed 0-8,000rpm

1-off HAAS TM1

Vertical Machining Centres
7.5HP Spindle
Capacity 762mm x 305mm x 406mm
Spindle Speed 0 to 10,500rpm

2-off HAAS VF3

Vertical Machining Centres
20HP Spindle Vector Drive
20 Tool Change
Capacity 1016mm x 508mm x 635mm
Spindle Speed 0 to 7,500rpm
Full 4th axis with HAAS HRT160 & HRT310 Rotary Tables

2-off HAAS Super Minimill

Vertical Machining Centres
15HP Vector Drive Spindle
20 Tool Change
Capacity 508mm x 405mm x 356mm
Spindle Speed 0 to 10,500rpm

1-off HAAS VF6D

Vertical Machining Centre
15kW Vector Drive Spindle
Table Size 1626mm x 711mm
Travel X1626mm x Y813mm x Z762mm
BT40 24 Tool Magazine
Through Spindle High Pressure Coolant
Spindle Speed 0-7,500rpm
Full 4th axis with HAAS HRT160 & HRT310 Rotary Tables
Renishaw Inspection probe and software

Doosan DVF5000 full 5-axis

Capacity (X, Y, Z axes): 625mm x 450mm x 400mm
Rotary tilting table (B- and C axes):-30+110; 360 degrees
Rapid rates (X, Y and Z): 40m/min
Table size: 500mm x 400mm
Max table load: 400kg
Spindle power/speed: Up to 22kW/18,000rpm
Tool changer: Up to 120 position
Control: Heidenhain initially; Fanuc and Siemens later in 2018




CNC Turning machines

1-OFF DOOSAN PUMA400MB

Turning Centre
30kW High Torque Motor
15” CHUCK
Ø116.5mm Bore
Spindle Speed 0-2,000rpm
Swing Over Saddle 770mm
Max Turning Diameter 560m
Max Turning Length 978mm
12Station 7.5kw live tooling

1-OFF DOOSAN PUMA2600LM

Turning Centre
22kW High Torque Motor
10” CHUCK
Ø76mm Bore
Spindle Speed 0-3,500rpm
Swing Over Saddle 780mm
Max Turning Diameter 376mm
Max Turning Length 1280mm
12Station 5.5kw live tooling

1-OFF DOOSAN PUMA240M

Turning Centre
22kW High Torque Motor
8” CHUCK
Ø65mm Bore
Spindle Speed 0-4,500rpm
Max Turning Diameter 350mm
Max Turning Length 562mm
12Station 5.5kw live tooling

1-OFF DOOSAN PUMA220LSY

Turning Centre
15kW High Torque Motor
6” CHUCK
Spindle Speed 0-5,000rpm
Swing Over Saddle 510mm
Max Turning Diameter 250mm
Max Turning Length 510mm
12Station live tooling

​​1-OFF MAZAK NEXUS 250

2 axis Turning Centre
26kW High Torque Motor
10” Chuck
Spindle Speed 0-4,000rpm
Max Turning Diameter 350mm
Ø3” bar capacity with magazine bar feed
Programmable tail stock

1-OFF HARRISON ALPHA 550

CNC Lathe
15HP 3gears 15-1800rpm
Swing: 830mm in gap, 554mm over bed, 370mm over cross slide
2000mm between

1-OFF HAAS TL1




CAD CAM

Solidworks/SolidCam

turning and milling




CMM

Aberlink AXIOM TOO CMM

640x900x500 with Aberlink software
offline programming and programming from model

DEA Mistral 1077
